High Speed Mini Cup Filler Machine is an easy to operate machine. The machine makes use of microcomputer so as to control the mini pump. It works according to the filling time and rotation rate. The machine works with high accuracy and is demanded in the sectors of medical, perfume filling, food, beverages, and cosmetics etc. High Speed Mini Cup Filler Machine it totally suitable for dealing with free flowing low viscous liquids. It can be used with an automatic as well as manual way. Performance of the said machine is stable. This is provided with a LCD display as well as simple to operate control panel.
SPECIFICATIONS
Products
Namkeen, Pulses, Granules. Tea, Spices etc.
Filling system
Adjustable Telescopic Disc, Volumetric cup filler
Filling Accuracy
± 1-1.5% (Depend on nature of product)
Type of Seal
Centre Seal, Back Seal and Three side seal
Filling range
2 gm upto 100 gms. (Depend on nature of product)
Packing Material
Heat Sealable Laminated Films
Pouch Dimensions
Width- 50-130mm, length- 50-150mm
Power Consumption
2.5 Kw
Compressed Air Required
6 CFM @ 66 Bar (2 H.P. Compressor)
Production Output
20-50 pouches per minute (depend on nature & quantity of product)
