14 Head Weigher with Servo Bagger is suited to be used in the consumer products. This is suited for a wide variability of packaging applications. This is used for the packaging of salt, sugar, spices, tea, snack foods, detergent, candies, wafers, milk, sauce, etc. It is made for the heat-sealable plastic. 14 Head Weigher with Servo Bagger Granules is used for packing and bagging the potato chips, fryums, kurkure, dry fruit, namkeen, etc. This is accessible with ultimate flexibility and can be functioned in dusty as well as wet environment.
SPECIFICATIONS
Products :
Namkeen, Pulses, Granules, Tea, Chips, Fryums etc
Filling system :
14 Head and 20 Head
Filling Accuracy :
+1-1.5% (Depend on nature of product)
Type of Seal :
Center Seal and Back Seal
Filling Range :
25gm upto 1000 gm (depend on nature of product)
Packing material :
Heat Sealable Laminated Films
Pouch Dimensions :
Width 60-200mm, Length 50-300mm
Power Consumption :
5.5 KW, Single Phase
Compressed Air Required :
6CFM@6 Bar (2 H.P. Compressor)
Production Output :
90-110 pouches per minute (Depend on nature & quantity of product)
Weight :
950 Kg (apprx.)
Machine Size (Bagger Size :
L-1880mm, W - 1270mm, H -1500mm (Apprx.)
Connect With us
14 Head Weigher with Servo Bagger Model No. FP-504
